Features Input operation voltage (min): 170 V Number of input phases: 1 Power protection features: Short circuit, Overload Output power capacity: 0.85 kVA UPS topology: Line-Interactive Number of output phases: 1 Input frequency: 50 Hz Output frequency: 50 Hz Output operation voltage (max): 230 V Output power: 480 W Waveform: Sine Input operation voltage (max): 280 V
Design Display type: LCD Product colour: Black International Protection (IP) code: IP20 Form factor: Tower
Operational conditions Storage relative humidity (H-H): 0 - 90% Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 143 mm Package height: 230 mm Width: 100 mm Package width: 140 mm Weight: 5.2 kg Depth: 290 mm
Ports & interfaces AC outlets quantity: 2 AC outlet(s)
Battery Cold start: Yes Number of batteries supported: 1 Battery capacity: 9 Ah Battery voltage: 12 V Battery technology: Sealed Lead Acid (VRLA)
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
