Features Power protection features: Overload, Short circuit Input frequency: 50 Hz Input operation voltage (max): 281 V Number of input phases: 1 Emergency Power Off (EPO): Yes UPS topology: Line-Interactive Input operation voltage (min): 178 V Maximum current: 16 A Number of output phases: 1 Waveform: Sine Output operation voltage (min): 195 V Automatic Voltage Regulation (AVR): Yes Surge protection: Yes Output operation voltage (max): 253 V Output power: 3000 W Output power capacity: 3 kVA
Design Cooling type: Active Product colour: Black Form factor: Rackmount/Tower Display type: LCD LED indicators: Yes International Protection (IP) code: IP20
Operational conditions Storage relative humidity (H-H): 20 - 95% Operating relative humidity (H-H): 20 - 80% Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 1000 m Storage temperature (T-T): 0 - 45 °C
Weight & dimensions Weight: 42 kg Package height: 247 mm Width: 440 mm Package width: 547 mm Height: 132 mm Depth: 630 mm
Packaging data Manual: Yes Quick installation guide: Yes Cables included: Input power cable Rubber feet: Yes
Ports & interfaces AC outlets quantity: 9 AC outlet(s) AC outlet types: C19 coupler, C13 coupler USB 2.0 ports quantity: 1 Ethernet LAN (RJ-45) ports: 1 Power plug: C20 coupler
Battery Cold start: Yes Battery capacity: 7 Ah Number of batteries supported: 8 Typical backup time at full load: 3 min Battery voltage: 12 V Typical backup time at half load: 7 min Battery recharge time: 4 h
Other features Number of phases: 1
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
