Design
LED indicators: Link, PoE, Activity
Housing material: Metal
Product colour: White
Rack mounting: No
Stackable: No
Number of fans: 1 fan(s)
Redundant fans support: Yes
Power
AC input voltage: 100 - 240 V
Power source: AC
Power supply included: Yes
Security
Loop protection: Yes
MAC address filtering: Yes
IGMP snooping: Yes
DHCP features: DHCP server, DHCP client, DHCP relay
Operational conditions
Operating temperature (T-T): -20 - 65 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Width: 200 mm
Weight: 8 kg
Depth: 180 mm
Height: 260 mm
Network
Networking standards: IEEE 802.3z, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates: 10,100,1000 Mbit/s
Active link detection: Yes
Cable types supported: Cat6, Cat5e
10G support: No
Packaging data
Package type: Box
Packaging content
Manual: Yes
Ports & interfaces
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Fiber optic connector: LC
Data transmission
MAC address table: 16384 entries
Switching capacity: 20 Gbit/s
Throughput: 14.88 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE) type supported: Active PoE
Power over Ethernet (PoE): Yes
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself., Ensure the unit is adequately ventilated during operation.
