Design
LED indicators: Power, Link, PoE
Rack mounting: Yes
Number of fans: 1 fan(s)
Stackable: No
Product colour: Black
Reset button: Yes
Form factor: 1U
Power
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power supply included: Yes
Power source: AC
Management features
Quality of Service (QoS) support: No
Cloud-managed: No
Switch layer: L2
Traffic classification: No
Configuring Location Settings (CLI): No
User operation log: No
Web-based management: No
Switch type: Unmanaged
Traffic shaping: No
System event log: No
Weight & dimensions
Width: 285 mm
Height: 44 mm
Depth: 180 mm
Network
Copper ethernet cabling technology: 100BASE-TX
Ethernet LAN data rates: 10,100 Mbit/s
Auto-negotiation: Yes
Networking standards: IEEE 802.3at, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3u, IEEE 802.3i
Auto-sensing: Yes
10G support: No
Packaging content
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: 16
Fast Ethernet (copper) ports quantity: 16
Combo SFP ports quantity: 1
Gigabit Ethernet (copper) ports quantity: 2
Data transmission
Store-and-forward: Yes
Forwarding rate: 3.868 Mpps
MAC address table: 16000 entries
Switching capacity: 5.2 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) pass through: No
Total Power over Ethernet (PoE) budget: 150 W
Power over Ethernet (PoE) type supported: Active PoE
Power over Ethernet (PoE) ports quantity: 16
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE) voltage: 48 V
