Design
Form factor: Spherical
Protection features: Waterproof
Weatherproof: Yes
Mounting type: Wall
International Protection (IP) code: IP67
Product colour: White
Power
Power consumption (max): 18 W
DC output voltage: 12
DC output current: 1.5 A
Power source type: DC
Security
Digital watermark: Yes
Anti-flicker: Yes
Security algorithms: WPA2, WPA, WPA-PSK, WPA-PSK2, WEP
Password protection: Yes
Intelligent Video Surveillance (IVS) system features: Human detection, Vehicle detection
Heartbeat: Yes
Built-in siren: Yes
Operational conditions
Operating temperature (T-T): -30 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Depth: 168.8 mm
Width: 112 mm
Height: 156.3 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b
Wi-Fi: Yes
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Ethernet LAN: Yes
Channel bandwidth: 20 MHz
Performance
Infrared (IR) cut-off filter: Yes
Type: IP security camera
Day/night mode: Yes
Auto-tracking: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Outdoor
Connectivity technology: Wired
Packaging data
Package width: 176 mm
Package height: 194 mm
Package depth: 205 mm
Package weight: 979.89 g
Packaging content
Number of cameras: 1
Cables included: DC
Screws included: Yes
Drilling template included: Yes
Storage
Maximum memory card size: 512 GB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera pan control: Yes
Minimum illumination: 0.05 lx
Camera tilt control: Yes
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 3 mm (1 / 3")
Video
Maximum resolution: 2560 x 1440 pixels
Video formats supported: H.265, H.264
Digital Wide Dynamic Range (DWDR): Yes
Back Light Compensation (BLC): Yes
Image quality adjustment: DNR
Night vision
Night vision distance: 30 m
Night vision: Yes
B/W night vision distance: 30 m
Colour night vision distance: 30 m
Lens system
Number of lenses: 3
Sustainability
Compliance certificates: RoHS, CE, WEEE, UL, REACH
