Technical details
Lens mount interface: M12
Design
Product colour: White
Weatherproof: Yes
Form factor: Dome
Mounting type: Ceiling/wall
Power
Power consumption (max): 12 W
DC output current: 1 A
Power source type: DC, PoE
DC output voltage: 12
Security
Digital watermark: Yes
Heartbeat: Yes
Intelligent Video Surveillance (IVS) system features: Human detection
Video motion detection: Yes
Anti-flicker: Yes
Password protection: Yes
Configurable region: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 50 °C
Management features
Cloud services supported: EZVIZ Cloud
Weight & dimensions
Weight: 525 g
Height: 136 mm
Width: 100 mm
Depth: 140 mm
Network
Bluetooth: No
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Performance
Built-in light: Yes
Connectivity technology: Wired
Auto-tracking: Yes
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Placement supported: Outdoor
Packaging data
Package height: 192 mm
Package width: 140 mm
Package weight: 745 g
Package depth: 140 mm
Packaging content
Drilling template included: Yes
Waterproof connector: Yes
Quick start guide: Yes
Manual: Yes
AC adapter included: Yes
Screws included: Yes
Number of cameras: 1
Audio
Built-in microphone: Yes
Audio system: 2-way
Built-in speaker(s): Yes
Storage
Maximum memory card size: 512 GB
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, horizontal: 89°
Lens viewing angle, diagonal: 104°
Lens viewing angle, vertical: 46°
Tilt angle range: 0 - 80°
Pan range: 0 - 350°
Minimum illumination: 0 lx
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Number of sensors: 1
Video
Maximum resolution: 2304 x 1296 pixels
Frame rate: 30 fps
Video streaming: Yes
Noise reduction technology: 3D noise reduction
Video formats supported: H.265, H.264
Noise reduction: Yes
Video compression formats: H.265, H.264
Digital Wide Dynamic Range (DWDR): Yes
Night vision
B/W night vision distance: 30 m
LED type: IR/White
Night vision: Yes
Night vision distance: 30 m
Lens system
Number of lenses: 1
Fixed focal length: 4 mm
Maximum aperture number: 1.6
Sustainability
Sustainability compliance: Yes
Compliance certificates: UKCA, RoHS, CE, Federal Communications Commission (FCC), WEEE, REACH
