Certification: REACH,RoHS,WEEE,CE
Technical details
Speakerphone: Yes
Number of displays supported: 1
Colour: Yes
Maximum number of cameras supported: 1
Compliance certificates: REACH, WEEE, RoHS, CE
Frequency band: 2.4/5 GHz
Connectivity technology: Wired & Wireless
Built-in microphone: Yes
Design
Waterproof: Yes
Product colour: Black, Silver
Power
Operating voltage (door opener): 24 V
Operating current (door opener): 1.5 A
Indoor unit power type: DC
Power consumption (typical): 8 W
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -10 - 45 °C
Weight & dimensions
Height: 111.6 mm
Width: 180.3 mm
Depth: 15.2 mm
Weight: 639 g
Network
Wi-Fi: Yes
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac)
Packaging data
Outdoor unit included: Yes
Screwdriver included: Yes
Indoor unit included: Yes
Package weight: 1.5 kg
Mounting kit: Yes
Display
Video formats supported: H.264, H.265
Display diagonal: 17.8 cm (7")
Display resolution: 1024 x 600 pixels
Audio
Built-in speaker(s): Yes
Number of ringtones: 20
Audio system: 2-way
Storage
Compatible memory cards: MicroSD (TransFlash)
Memory card slot: Yes
Maximum memory card size: 512 GB
Camera
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Maximum image resolution: 1920 x 1080 pixels
Maximum frame rate: 15 fps
Logistics data
Quantity per pack: 1 pc(s)
Night vision
LED type: IR
Night vision distance: 6 m
Night vision: Yes
