Technical details
Colour: Yes
Number of displays supported: 1
Connectivity technology: Wired
Built-in microphone: Yes
Speakerphone: Yes
Frequency band: 2.4/5 GHz
Maximum number of cameras supported: 1
RFID reader: Yes
Motion detection function: Yes
Design
Product colour: Black, Grey
Waterproof: Yes
Power
Operating current (door opener): 1 A
Power consumption (typical): 8 W
Power consumption (max): 36 W
Operating voltage (door opener): 24 V
Indoor unit power type: DC
Operational conditions
Main monitor station operating temperature (T-T): 10 - 45 °C
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Door station dimensions (WxDxH): 91 x 40 x 191.8 mm
Depth: 15 mm
Height: 123 mm
Width: 200.3 mm
Weight: 1.13 kg
Network
Networking standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Security algorithms: WPA, WPA2, WPA-PSK, WPA3, WPA2-PSK, WPA3-PSK
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Packaging data
Indoor unit included: Yes
Package weight: 2.42 kg
Mounting kit: Yes
Outdoor unit included: Yes
Screwdriver included: Yes
Display
Video formats supported: H.264, H.265
Display diagonal: 20.3 cm (8")
Touchscreen: Yes
Display resolution: 1280 x 800 pixels
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Number of ringtones: 20
Storage
Maximum memory card size: 512 GB
Compatible memory cards: MicroSD (TransFlash)
Memory card slot: Yes
Camera
Motion sensor: Yes
Maximum aperture number: 1.6
Sensor type: CMOS
Maximum frame rate: 15 fps
Fixed focal length: 2 mm
Viewing angle, diagonal: 158°
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Maximum image resolution: 3840 x 2160 pixels
Night vision
Night vision: Yes
LED type: IR
