Technical details
Lens mount interface: M12
Design
Mounting type: Ceiling/wall
Form factor: Bullet
Protection features: Water resistant
International Protection (IP) code: IP65
Product colour: Black
Power
Rechargeable battery: Yes
Power consumption (max): 10 W
Battery capacity: 10400 mAh
DC output voltage: 5
Power source type: Battery, DC
DC output current: 2 A
Security
Heartbeat: Yes
Anti-flicker: Yes
Security algorithms: WPA2-PSK, WPA-PSK, WPA3-Personal
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Human detection
Video motion detection: Yes
Digital watermark: Yes
Password protection: Yes
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Cloud services supported: EZVIZ Cloud
Weight & dimensions
Height: 63 mm
Width: 63 mm
Weight: 348 g
Length: 149.3 mm
Network
Channel bandwidth: 20 MHz
Frequency band: 2.4 - 2.4835 GHz
Works with the Google Assistant: Yes
Bluetooth: Yes
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n)
Ethernet LAN: No
Wi-Fi: Yes
Works with Amazon Alexa: Yes
Wi-Fi data rate (max): 114 Mbit/s
Performance
Built-in light: Yes
Type: IP security camera
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Connectivity technology: Wireless
Placement supported: Outdoor
Packaging data
Package width: 103 mm
Package weight: 671 g
Package height: 186 mm
Package depth: 103 mm
Packaging content
Cables included: USB
Mounting kit: Yes
Quick start guide: Yes
Number of cameras: 1
Mounting brackets included: Yes
Drilling template included: Yes
Screws included: Yes
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB
Built-in HDD: No
Card reader integrated: Yes
Ports & interfaces
DC-in jack: Yes
Camera
Adjustment shutter speed: Auto
Minimum illumination: 0 lx
Lens viewing angle, vertical: 60°
Lens viewing angle, diagonal: 135°
Lens viewing angle, horizontal: 113°
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Frame rate: 15 fps
Supported graphics resolutions: 3840 x 2160
Video recording: Yes
Video streaming: Yes
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.264, H.265
Supported video modes: 2160p, 1080p, 1440p
Noise reduction: Yes
Total megapixels: 8 MP
Video formats supported: H.265, H.264
Bit rate: 4 Mbps
Noise reduction technology: 3D noise reduction
Night vision
LED type: IR/White
Night vision distance: 15 m
Colour night vision distance: 15 m
Night vision: Yes
Lens system
Fixed focal length: 2.8 mm
Maximum aperture number: 1.6
Number of lenses: 1
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Sustainability
Compliance certificates: REACH, UL, RoHS, CE, WEEE
