Design
Product colour: Black
International Protection (IP) code: IP65
Form factor: Bullet
Mounting type: Ceiling/wall
Power
Power consumption (max): 10 W
DC output voltage: 5
Power source type: Battery, DC, Solar
DC output current: 2 A
Battery capacity: 5200 mAh
Security
Video motion detection: Yes
Digital watermark: Yes
Password protection: Yes
Heartbeat: Yes
Anti-flicker: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -20 - 50 °C
Management features
Cloud services supported: EZVIZ Cloud
Cloud-managed: Yes
Weight & dimensions
Weight: 222.7 g
Length: 153.3 mm
Width: 63 mm
Network
Bluetooth: No
Channel bandwidth: 20 MHz
Wi-Fi: Yes
Ethernet LAN: No
Performance
Connectivity technology: Wireless
Day/night mode: Yes
Placement supported: Outdoor
Infrared (IR) cut-off filter: Yes
Type: IP security camera
Packaging data
Package weight: 569 g
Package height: 186 mm
Package width: 103 mm
Package depth: 103 mm
Packaging content
Quick start guide: Yes
Number of cameras: 1
Cables included: DC
Mounting kit: Yes
Mounting brackets included: Yes
Battery included: Yes
Drilling template included: Yes
Screws included: Yes
Audio
Audio system: 2-way
Built-in microphone: Yes
Built-in speaker(s): Yes
Storage
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Maximum memory card size: 512 GB
Card reader integrated: Yes
Camera
Lens viewing angle, vertical: 56°
Lens viewing angle, diagonal: 130°
Lens viewing angle, horizontal: 108°
Image sensor
Number of sensors: 1
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Video
Maximum resolution: 2304 x 1296 pixels
Noise reduction: Yes
Video formats supported: H.264, H.265
Video recording: Yes
Noise reduction technology: 3D noise reduction
Bit rate: 1.5 Mbps
Supported graphics resolutions: 2304 x 1296
Frame rate: 15 fps
Video compression formats: H.265, H.264
Total megapixels: 3 MP
Night vision
LED type: IR
Night vision distance: 15 m
Night vision: Yes
Colour night vision distance: 15 m
Lens system
Fixed focal length: 2.8 mm
Number of lenses: 1
Maximum aperture number: 1.6
Sustainability
Compliance certificates: WEEE, RoHS, CE, UKCA, REACH, Federal Communications Commission (FCC)
