Design
Product colour: White
Product type: IP Phone
Mounting: Desk
Handset type: Wired handset
Power
Power consumption (Power over Ethernet (PoE)): 5.65 W
AC adapter output voltage: 5 V
Power over Ethernet (PoE): Yes
AC adapter output current: 2 A
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 95%
Management features
Keypad number of keys: 26
Number of programmable keys: 6
Weight & dimensions
Package depth: 210 mm
Height: 131.7 mm
Package height: 125 mm
Width: 151.7 mm
Depth: 193.2 mm
Package width: 225 mm
Network
Quality of Service (QoS) support: Yes
DHCP client: Yes
Bluetooth: No
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b
Syslog: Yes
Wi-Fi: Yes
Ethernet LAN: Yes
Performance
Dual-Tone Multi-Frequency (DTMF) modes: In-band, Out-of band, SIP info
Packaging content
Cables included: RJ-9
Number of handles included: 1 pc(s)
Display
Display diagonal: 8.89 cm (3.5")
Touchscreen: No
Display: LCD
Display resolution: 480 x 320 pixels
Audio
Microphone mute: Yes
Voice codecs: G.729A, G.711a, G.711u, G.729B, G.722, iLBC
Packet loss concealment (PLC): Yes
Adaptive jitter buffers: Yes
Comfort noise generation (CNG): Yes
Speakerphone: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
RJ-9 ports quantity: 1
Phone features
Lines quantity: 2 lines
Full duplex: Yes
Redialing: Yes
Message-waiting indicator (MWI): Yes
Call log entries: 600
Call hold: Yes
Speed dialling: Yes
Call transfer: Yes
