Design
Product colour: Black
Handset type: Wired handset
Product type: IP Phone
Wall mountable: Yes
Mounting: Desk/Wall
Power
Power over Ethernet (PoE): Yes
Power consumption (typical): 8 W
Input current: 2 A
Power consumption (Power over Ethernet (PoE)): 9 W
Operational conditions
Operating relative humidity (H-H): 10 - 95%
Operating temperature (T-T): 0 - 45 °C
Management features
Firmware upgradeable: Yes
Number of function keys: 6
Keypad number of keys: 77
Weight & dimensions
Package width: 323 mm
Package height: 71 mm
Width: 309 mm
Depth: 214 mm
Package depth: 301 mm
Height: 187 mm
Network
Wi-Fi: No
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Supported network protocols: SIP2.0, RTP/RTCP/SRTP, STUN, DHCP, IPv6, LDP, PPPoE, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
Syslog: Yes
Ethernet LAN: Yes
Bluetooth: Yes
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.1x
Bluetooth version: 4.2
Packaging content
Number of handles included: 1 pc(s)
Cables included: LAN (RJ-45)
Display
Touchscreen: No
Display: LCD
Display diagonal: 10.9 cm (4.3")
Audio
Voice codecs: G.711a, G.729ab, AMR, iLBC, G.722, G.726-32, G.711u, G.723.1, AMR-WB, OPUS
Noise reduction: Yes
Microphone mute: Yes
Echo cancellation: Yes
Speakerphone: Yes
Voice activity detection: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
DC-in jack: Yes
RJ-9 ports quantity: 2
Video
Video codecs: H.264
Video call: Yes
Phone features
Call waiting: Yes
Phonebook capacity: 2000 entries
Speed dialling: Yes
Intercom: Yes
Call forwarding: Yes
Anonymous call: Yes
Call hold: Yes
Do not disturb function: Yes
Lines quantity: 20 lines
Redialing: Yes
Call transfer: Yes
Caller ID: Yes
Call log entries: 1000
Conference call: Yes
Call park: Yes
Call pick up: Yes
Phonebook sharing: Yes
Answering machine: Yes
