Design
LED indicators: Link, LAN, Stand-by, Status
Product colour: Grey, Black
Stackable: No
Form factor: 1U
Rack mounting: Yes
Housing material: Metal
Temperature sensor: Yes
Number of fans: 2 fan(s)
Power
AC input voltage: 100 - 240 V
Power source: AC
Number of power supply units: 1
Power supply included: Yes
AC input frequency: 50 - 60 Hz
Security
DHCP features: DHCP snooping, DHCP Option 82, DHCP client, DHCP relay, DHCPv6 snooping
Security algorithms: SNMP, SNMPv3, SNMPv2
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -20 - 55 °C
Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Switch layer: L2/L3
Web-based management: Yes
Weight & dimensions
Width: 440 mm
Depth: 190 mm
Height: 44 mm
Weight: 3.8 kg
Network
Number of VLANs: 4096
VLAN mapping type: 1:1 VLAN mapping, N:1 VLAN mapping
10G support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Virtual LAN features: VLAN mapping
Full duplex: Yes
Port mirroring: Yes
VLAN support: Yes
Networking standards: IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p
Performance
Built-in processor: Yes
Packaging data
Package type: Box
Packaging content
Rack mount kit: Yes
Cables included: AC
Protocols
IPv4 & IPv6 features: IPv6 ping, IPv6 Telnet, IPv4/IPv6 access-control list (ACL)
Ports & interfaces
Fiber optic connector: SFP+
Installed SFP+ modules quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 24
Gigabit Ethernet (copper) ports quantity: 24
Data transmission
Throughput: 96 Mpps
Switching capacity: 128 Gbit/s
MAC address table: 16384 entries
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
