Design
Stackable: No
Temperature sensor: Yes
Housing material: Metal
Rack mounting: Yes
Number of fans: 3 fan(s)
LED indicators: Link, Power, PoE, Stand-by, LAN, Status
Form factor: 1U
Product colour: Grey, Black
Power
Number of power supply units: 1
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 400 W
Power source: AC
Security
DHCP features: DHCP client, DHCP relay, DHCP server, DHCPv6 client, DHCP Option 82, DHCP snooping, DHCPv6 snooping, DHCPv6 relay
IGMP snooping: Yes
Security algorithms: SNMPv2, SNMPv3, SNMP
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -20 - 55 °C
Management features
Configuring Location Settings (CLI): Yes
Switch layer: L2/L3
Switch type: Managed
System event log: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 4 kg
Depth: 290 mm
Height: 44 mm
Width: 440 mm
Network
Number of VLANs: 4096
Full duplex: Yes
VLAN support: Yes
Port mirroring: Yes
10G support: Yes
VLAN mapping type: 1:1 VLAN mapping, N:1 VLAN mapping
Link aggregation: Yes
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.3ab
Ethernet LAN data rates: 10,100,1000 Mbit/s
Performance
Built-in processor: Yes
Packaging data
Package type: Box
Packaging content
Rack mount kit: Yes
Cables included: AC
Protocols
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 portal, IPv6 ping
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Fiber optic connector: SFP+
Power connector: AC-in jack
Installed SFP+ modules quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
Data transmission
Throughput: 96 Mpps
MAC address table: 16384 entries
Switching capacity: 128 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: Active PoE
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE) ports quantity: 24
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
