Features
Video formats supported: MPEG4
Image formats supported: JPG
Certification: MFi, RoHS, CE/FCC, CEC-BC, EN61233
Design
Operating temperature (T-T): 0 - 35 °C
Housing material: Metal
Drop proof: 180 cm
Storage temperature (T-T): -20 - 60 °C
Product colour: Black
Weight & dimensions
Depth: 34 mm
Height: 14 mm
Width: 68 mm
Weight: 36.5 g
Performance
Horizontal field of view: 55°
Accuracy: 3 °C, 5 °F
Thermal sensitivity (NETD): 150 mK
Temperature measurement range: -20 - 400 °C
Image frequency: 8.7 Hz
Standard palettes: Color, Grayscale, High Contrast, Ice Fire, Rainbow
Vertical field of view: 43°
Maximum resolution: 160 x 120 pixels
Sensor type (thermal module): Noise equivalent temperature difference (NETD)
Camera pixel size: 12 µm
Ports & interfaces
USB connector type: USB Type-C
Battery
Battery life (max): 1 h
Battery level indicator: Yes
Battery recharge time: 0.66 h
Lens system
Sensor resolution (thermal module): 160 x 120 pixels
Optical module
Fixed focus: Yes
