Design
International Protection (IP) code: IP66
Form factor: Bullet
Product colour: Black
Mounting type: Ceiling/wall
Weatherproof: Yes
Power
Power source type: DC
DC output current: 1 A
Power consumption (max): 5 W
DC output voltage: 12
Security
Alert notification type: Text alert message
Video motion detection: Yes
IP address filtering: Yes
Operational conditions
Storage relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 80%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width: 65 mm
Length: 98 mm
Weight: 255 g
Height: 62 mm
Network
Wi-Fi standards: 802.11g, 802.11b
Supported network protocols: WPA, WPA2, IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, UPnP, RTSP, ONVIF
Ethernet LAN: Yes
Wi-Fi: Yes
Ethernet interface type: Fast Ethernet
System requirements
Mobile operating systems supported: iOS, Android
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Certification: FCC, IC, CE, WEEE
Performance
Infrared (IR) cut-off filter: Yes
Placement supported: Outdoor
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Day/night mode: Yes
Connectivity technology: Wireless
Packaging content
Number of cameras: 1
Audio
Audio system: 2-way
Audio formats supported: PCM, G.726
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
Microphone in: Yes
Camera
Lens viewing angle, diagonal: 112°
Lens viewing angle, horizontal: 89°
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 2.6 mm (1 / 2.6")
Sensor type: CMOS
Video
Image quality adjustment: Saturation, Sharpness, Contrast, Brightness
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 320 x 240
Frame rate: 25 fps
Flip & mirror: Yes
Total megapixels: 4 MP
Video compression formats: H.264
Maximum resolution: 2560 x 1440 pixels
Video formats supported: H.264
Night vision
Number of illumination LEDs: 30
LED type: IR
Night vision: Yes
Night vision distance: 20 m
Lens system
Number of lenses: 1
Fixed focal length: 4 mm
Maximum aperture number: 2.2
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., The product contains electronic components; do not dispose of with the normal household waste., Ensure that the product is properly installed and protected against falling.
