Features Waveform: Sine Input operation voltage (max): 300 V Input operation voltage (min): 120 V Output power: 2700 W Input frequency: 40 - 70 Hz Total Harmonic Distortion (THD) (linear load): 3% Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm Output operation voltage (min): 200 V Crest factor: 3:1 Total Harmonic Distortion (THD) (non-linear load): 6% Noise level: 50 dB Response time: 0 ms Audible alarm(s): Yes Output operation voltage (max): 240 V Output power capacity: 3 kVA Output voltage regulation: 1% UPS topology: Double-conversion (Online) Power factor: 0.99 Output frequency: 47/63 Hz
Design Form factor: Tower LED indicators: Yes Control type: Buttons Product colour: Black Display type: LCD
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 20 - 90%
Weight & dimensions Width: 190 mm Height: 318 mm Depth: 421 mm Weight: 27.6 kg
Packaging data Software CD: Yes
Packaging content Cables included: Input power cable, USB cable Manual: Yes Batteries included: Yes
Ports & interfaces Serial interface: Yes RS-232 ports: 1 USB port type: USB Type-B USB 2.0 ports quantity: 1 Serial interface type: RS-232 Number of output IEC jumpers: 4 AC outlet types: C13 coupler USB port: Yes
Battery Typical backup time at half load: 9.8 min Number of battery cells: 6 Battery recharge time (90%): 4 h Battery voltage: 12 V Battery capacity: 9 Ah Typical backup time at full load: 3.5 min
Logistics data Harmonized System (HS) code: 85078000
