Design Cooling type: Active On/off switch: Yes Product colour: Black Fan location: Top Fan diameter: 9.2 cm Number of fans: 1 fan(s)
Power Power protection features: Over power, Overheating, Short circuit, Over voltage, Over current Max output current (+12V): 54 A Combined power (+3.3V): 120 W AC input voltage: 100 - 240 V Combined power (+5Vsb): 12.5 W Max output current (-12V): 0.3 A AC input frequency: 50 - 60 Hz Maximum input current (@220V): 5 A Max output current (+5V): 22 A Max output current (+5Vsb): 2.5 A Combined power (-12V): 3.6 W Combined power (+12V): 648 W Total power: 650 W Combined power (+5V): 120 W Efficiency: 90% Maximum input current (@110V): 10 A Max output current (+3.3V): 20 A
Weight & dimensions Height: 63.5 mm Width: 100 mm Depth: 125 mm
Performance Silent mode: Yes Purpose: PC Power supply unit (PSU) form factor: SFX Bearing technology: Ball bearing Mean time between failures (MTBF): 200000 h 80 PLUS certification: 80 PLUS Gold Noise level: 40 dB
Packaging content Cables included: CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces Floppy drive power connector: 1 CPU power cable length: 85 cm PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power connectors (4-pin): 2 Cabling type: Fully-Modular EPS power connector (4+4 pin): Yes Number of SATA power connectors: 5 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes
Logistics data Harmonized System (HS) code: 84733020
