Design
Cooling type: Active
Fan diameter: 4 cm
Number of fans: 1 fan(s)
Power
AC input frequency: 47 - 63 Hz
Max output current (+5Vsb): 2.5 A
Max output current (+12V): 18 A
Combined power (+3.3V): 80 W
Max output current (+3.3V): 12 A
Efficiency: 85%
Combined power (+5V): 80 W
Input current: 2 - 4 A
Max output current (+5V): 14 A
AC input voltage: 90 -264 V
Total power: 250 W
Power Factor Correction (PFC) type: Active
Max output current (-12V): 0.3 A
Hold time: 16 ms
Operational conditions
Operating relative humidity (H-H): 0 - 85%
Operating temperature (T-T): 0 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 80 °C
Weight & dimensions
Height: 81.5 mm
Width: 150 mm
Depth: 40.5 mm
Performance
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS
Power supply unit (PSU) form factor: Flex ATX
Certification: CB 62368, CE, EMC, FCC, TUV, CUL, CCC, BSMI, UKCA, KC
Certificates
Compliance certificates: RoHS
