Design
Product colour: Black
Fan location: Top
Cooling type: Active
On/off switch: Yes
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Power
AC input voltage: 100 - 240 V
Power protection features: Short circuit, Over voltage, Over current, Over power, Overheating
Combined power (-12V): 18.6 W
Total power: 1000 W
Combined power (+5V): 120 W
Max output current (+3.3V): 20 A
Input current: 13-6 A
Combined power (+5Vsb): 18.6 W
Combined power (+12V): 1000 W
Efficiency: 94%
Combined power (+3.3V): 120 W
Max output current (+12V): 83.33 A
AC input frequency: 50/60 Hz
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Weight & dimensions
Depth: 150 mm
Width: 150 mm
Height: 86 mm
Performance
Power supply unit (PSU) form factor: ATX
EPS version: 2.92
80 PLUS certification: 80 PLUS Titanium
Noise level: 15 dB
Purpose: PC
Bearing technology: FDB
ATX version: 3.0
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 4
PCI Express power connectors (6+2 pin): 5
Cabling type: Fully-Modular
Motherboard power cable length: 60 cm
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 12
PCI Express power connectors (12+4 pin) cable length: 700 mm
CPU power cable length: 70 cm
Safety warning
Warnings: Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
