Design Fan diameter: 12 cm Number of fans: 1 fan(s) Fan location: Top Product colour: Black Cooling type: Active
Power Combined power (+12V): 850 W Combined power (-12V): 3.6 W Efficiency: 90% Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Max output current (+3.3V): 20 A Combined power (+5V): 100 W Combined power (+3.3V): 100 W Combined power (+5Vsb): 15 W Power Factor Correction (PFC) type: Active Max output current (+12V): 70.83 A Power protection features: Overheating, Under voltage, Over current, Short circuit, Over voltage, Over power Total power: 850 W Max output current (+5V): 20 A AC input voltage: 100 - 240 V Input current: 11-5.5 A AC input frequency: 50/60 Hz
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Power supply unit (PSU) form factor: ATX ATX version: 3.1 EPS version: 2.92 Bearing technology: HYB 80 PLUS certification: 80 PLUS Gold Purpose: PC
Packaging content Cables included: CPU, Peripheral (Molex), SATA
Ports & interfaces Number of SATA power connectors: 8 CPU power connector (4+4 pin): Yes Motherboard power cable length: 60 cm Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 4 CPU power cable length: 70 cm SATA power cable length: 500 mm Motherboard power connector: 20+4 pin ATX Peripheral (Molex) power connectors (4-pin): 4
