Design
Number of fans: 2 fan(s)
Fan diameter: 4 cm
Product colour: Black
Power
Power protection features: Short circuit, Over voltage, Overheating, Over power, Under voltage, Over current
Combined power (+3.3V): 130 W
Power Factor Correction (PFC) type: Active
Max output current (+12V): 58.3 A
Total power: 700 W
Efficiency: 90%
Max output current (+5Vsb): 3 A
Combined power (+5V): 130 W
Max output current (+3.3V): 20 A
Max output current (+5V): 20 A
Max output current (-12V): 0.5 A
AC input frequency: 50 - 60 Hz
Input current: 10-5 A
AC input voltage: 100 - 240 V
Weight & dimensions
Depth: 190 mm
Height: 86 mm
Width: 150 mm
Performance
Power supply unit (PSU) form factor: PS/2
Bearing technology: Ball bearing
80 PLUS certification: 80 PLUS Gold
Purpose: Server
Packaging content
Cables included: CPU, PCIe, SATA
Ports & interfaces
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 4
Cabling type: Non-Modular
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power connectors (4-pin): 2
Logistics data
Harmonized System (HS) code: 84733020
Safety warning
Warnings: Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
