Fujitsu Intel Xeon Gold 5415+ processor 2.9 GHz 22.5 MB Box

Technical details
Number of UPI links: 3
Launch date: Q1'23
Memory speed (max): 4400 MHz
Status: Launched
Package carrier: E1B
Supported memory types: DDR5-SDRAM

Processor
High priority cores: 2
Processor generation: Intel Xeon Scalable 4th Gen
Processor base frequency: 2.9 GHz
High priority core frequency: 3.1 GHz
Low priority cores: 6
Processor threads: 16
Processor ARK ID: 232373
Thermal Design Power (TDP): 150 W
Processor cache: 22.5 MB
Processor socket: LGA 4677 (Socket E)
Processor manufacturer: Intel
Processor model: 5415+
Processor cores: 8
Processor family: Intel® Xeon® Gold
Processor codename: Sapphire Rapids
Processor boost frequency: 4.1 GHz
Stepping: S3
Package type: Box
System bus rate: 16 GT/s

Graphics
Discrete graphics card: No
On-board graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available

Features
Market segment: Server
Use conditions: Server/Enterprise
Supported instruction sets: AMX, AVX 2.0, AVX, SSE4.2, AVX-512
Scalability: 2S
Execute Disable Bit: Yes
PCI Express slots version: 5.0
Maximum number of PCI Express lanes: 80
Embedded options available: Yes

Memory
Maximum internal memory supported by processor: 6 TB
Memory channels: Octa-channel
ECC: Yes
Memory types supported by processor: DDR5-SDRAM

Operational conditions
DTS Max: 99 °C
Tcase: 78 °C

Weight & dimensions
Processor package size: 77.5 x 56.5 mm

Processor special features
Mode-based Execute Control (MBE): Yes
Intel® Boot Guard: Yes
AVX-512 Fused Multiply-Add (FMA) units: 2
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel® Resource Director Technology (Intel® RDT): Yes
Intel® Optane™ DC Persistent Memory Supported: Yes
Intel® Run Sure Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® On Demand Feature Activation: Yes
Maximum Enclave Size Support for Intel® SGX: 128 GB
Intel® Crypto Acceleration: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® QuickAssist Software Acceleration: Yes
Intel® Data Streaming Accelerator (DSA): 1 default devices
Intel® Advanced Matrix Extensions (AMX): Yes
Intel® In-memory Analytics Accelerator (IAA): 1 default devices
Intel® Transactional Synchronization Extensions: Yes
Intel® Platform Firmware Resilience Support: Yes
Intel® Dynamic Load Balancer (DLB): 1 default devices
Intel® QuickAssist Technology (QAT): 1 default devices
Intel® Total Memory Encryption: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel Virtualization Technology (VT-x): Yes
Intel Trusted Execution Technology: Yes
Intel® OS Guard: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel 64: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0

Other features
Maximum internal memory: 4 TB
