Technical details
Compliance certificates: RoHS, WEEE
Processor
Number of processors installed: 1
Processor cores: 8
Processor model: E-2388G
Processor family: Intel Xeon E
Motherboard chipset: Intel C256
Processor cache: 16 MB
Processor boost frequency: 4.6 GHz
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Processor frequency: 3.2 GHz
Memory
Memory clock speed: 3200 MHz
Internal memory type: DDR4-SDRAM
Memory slots: 4x DIMM
ECC: Yes
Maximum internal memory: 128 GB
Internal memory: 32 GB
Memory layout (slots x size): 1 x 32 GB
Design
Chassis type: Tower
Rack mounting: Yes
Redundant fans support: Yes
Product colour: Black
Power
Power supply input voltage: 100 - 240 V
Redundant power supply (RPS) support: Yes
Power supply input frequency: 50 / 60 Hz
Power supply: 500 W
Operational conditions
Operating relative humidity (H-H): 10 - 85%
Operating temperature (T-T): 5 - 45 °C
Weight & dimensions
Height: 456.2 mm
Depth: 521.7 mm
Weight: 26.4 kg
Width: 177.2 mm
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
LAN controller: Intel I210
Cabling technology: 10/100/1000Base-T(X)
Performance
Trusted Platform Module (TPM) version: 2.0
Trusted Platform Module (TPM): Yes
Noise level: 22 dB
Expansion slots
PCI Express x4 (Gen 3.x) slots: 2
PCI slots: 1
PCI Express x8 (Gen 4.x) slots: 2
Compatible operating systems: Windows Server 2022 Datacenter, Windows Server 2022 Standard, Windows Server 2022 Essentials, Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, VMware vSphere 7.0, Red Hat Enterprise Linux 8, Univention Corporate Server 4
Software
Operating system installed: No
Storage
Hot-Plug support: Yes
RAID support: Yes
Supported HDD sizes: 2.5"
Optical drive type: No
Ports & interfaces
Total number of SATA connectors: 7
USB 2.0 ports quantity: 4
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Sustainability
Sustainability compliance: Yes
