Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM4
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen PRO 3000 Series, AMD Ryzen 3000 Series, AMD Ryzen PRO 5000 Series, AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen PRO 4000 Series
Processor socket: Socket AM4
Graphics
Parallel processing technology support: Not supported
Maximum resolution: 5120 x 2880 pixels
DirectX version: 12.0
HDCP: Yes
HDCP version: 2.3
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Cooling type: Passive
Component for: PC
Power source type: ATX
Motherboard form factor: micro ATX
Product colour: Dark brown
Audio chip: Realtek ALC897
PC health monitoring: Fan, Temperature, Voltage
Motherboard chipset: AMD A520
Audio output channels: 7.1 channels
Memory
Supported memory clock speeds: 5100 MHz, 2133 MHz, 2667, 3733, 4400 MHz, 3466, 2933, 3600, 2400, 3400, 3866, 3200, 4266 MHz, 4600, 4133, 4000, 4800 MHz
Maximum internal memory: 64 GB
Number of memory slots: 2
Memory slots type: DIMM
Maximum internal memory per slot: 32 GB
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Supported memory types: DDR4-SDRAM
Supported memory clock speed (max): 5100 MHz
Unbuffered memory: Yes
Weight & dimensions
Width: 233 mm
Depth: 198 mm
Height: 35 mm
Network
LAN controller: Realtek RTL8111H
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
Number of chassis fan connectors: 2
TPM connector: Yes
EPS power connector (8-pin): Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
12V power connector: Yes
RGB LED pin header: Yes
Number of CPU fan connectors: 1
USB 2.0 connectors: 2
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
ACPI version: 5.0
BIOS memory size: 128 Mbit
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 52 mm
Package depth: 235 mm
Package weight: 772 g
Package width: 265 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Batteries included: Yes
Storage controllers
RAID levels: 10, 0, 1
RAID support: Yes
Number of storage drives supported: 5
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPort version: 1.4
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
PS/2 ports quantity: 1
HDMI ports quantity: 1
Microphone in: Yes
Line-in: Yes
Headphone outputs: 1
DisplayPorts quantity: 1
HDMI version: 2.1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 3.0
Battery
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery capacity: 220 mAh
Other features
Weight: 700 g
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
