Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Maximum internal memory supported by processor: 64 GB
Maximum number of SMP processors: 1
Compatible processor series: AMD Ryzen 3000 Series
Processor manufacturer: AMD
Graphics
On-board graphics card: No
HDCP: Yes
Features
Component for: PC
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Motherboard chipset: AMD A520
Product colour: Black
Memory
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Number of memory slots: 2
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 2400, 4866, 2933, 3600, 2133, 2667, 4400, 5000, 4000, 3333, 3200 MHz, 4600
Maximum internal memory: 64 GB
Weight & dimensions
Height: 35 mm
Width: 244 mm
Depth: 205 mm
Network
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Internal I/O
Number of chassis fan connectors: 2
Power fan connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
BIOS
BIOS memory size: 128 Mbit
ACPI version: 5.0
Clear CMOS jumper: Yes
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package depth: 235 mm
Package width: 265 mm
Package height: 52 mm
Package weight: 740 g
Packaging content
Batteries included: Yes
Storage controllers
RAID levels: 10, 1, 0
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA
RAID support: Yes
Rear panel I/O ports
DVI-D ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Battery
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Harmonized System (HS) code: 84733020
Country of origin: China
Safety warning
Warnings: Dispose of according to local electro-waste regulations., Avoid direct contact with sensitive electronic components., Store away from water and sources of moisture.
