Technical details
Warranty period: 3 year(s)
Processor
Maximum internal memory supported by processor: 96 GB
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Motherboard chipset family: AMD
Motherboard form factor: mini ITX
Audio output channels: 7.1 channels
PC health monitoring: Water cooling, Fan, Voltage, Temperature
Product colour: Bronze
Motherboard chipset: AMD A620
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 6400 MHz
Supported memory module capacities: 12GB, 1GB, 32GB, 16GB, 8GB, 48GB, 2GB, 4GB
Supported memory clock speeds: 5200, 6000, 4400, 6400, 6200, 4800, 5600
Unbuffered memory: Yes
Maximum internal memory: 96 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Height: 35 mm
Width: 170 mm
Depth: 170 mm
Network
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
WLAN controller model: Realtek RTL8852CE
Ethernet LAN: Yes
Wi-Fi: Yes
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
12V power connector: Yes
Total number of SATA connectors: 2
RGB LED pin header: Yes
Audio connector: Yes
CPU fan connector: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 2
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 1
Chassis intrusion connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
EPS power connector (8-pin): Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging data
Package weight: 860 g
Package height: 65 mm
Package depth: 180 mm
Package width: 222 mm
Bundled software: Norton Internet Security
Packaging content
Batteries included: Yes
Cables included: SATA
Storage controllers
Number of storage drives supported: 3
Number of HDDs supported: 2
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 1
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
Microphone in: Yes
Headphone outputs: 3
HDMI version: 2.1
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
USB connector type: USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
USB 2.0 ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Expansion slots
PCI Express x16 slots: 1
Number of M.2 (M) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery type: CR2032
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste.
