Technical details
Warranty period: 3 year(s)
Processor
Maximum internal memory supported by processor: 256 GB
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
HDCP: Yes
HDCP version: 2.3
Features
Motherboard chipset: AMD A620
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
PC health monitoring: Fan, Temperature, Voltage
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Memory
Supported memory clock speeds: 7000, 5600, 7200, 6000, 6600, 6400 MHz, 7600, 6200, 6800, 5200, 4800
Number of memory slots: 4
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speed (max): 7600 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 174 mm
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Ethernet LAN: Yes
Internal I/O
Total number of SATA connectors: 4
CPU fan connector: Yes
USB 2.0 connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Front panel connector: Yes
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
RGB LED pin header: Yes
12V power connector: Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Storage controllers
RAID levels: 1, 0, 10
Number of storage drives supported: 4
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
VGA (D-Sub) ports quantity: 1
Headphone outputs: 3
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
DisplayPort version: 1.4
Number of audio jack connectors: 3
USB connector type: USB Type-C, USB Type-A
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Expansion slots
PCI Express x16 slots: 1
PCI Express x1 slots: 1
Number of M.2 (M) slots: 1
Battery
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
