Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Maximum internal memory supported by processor: 96 GB
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series
Processor socket: Socket AM5
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Motherboard chipset family: AMD
Product colour: Bronze
PC health monitoring: Temperature, Voltage, Water cooling, Fan
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Motherboard chipset: AMD A620
Memory
Supported memory clock speeds: 6000, 4400, 6200, 4800, 6400, 6800, 5200, 5600, 7200 MHz
Maximum internal memory: 96 GB
Supported memory module capacities: 12GB, 32GB, 2GB, 4GB, 8GB, 48GB, 1GB, 16GB
Unbuffered memory: Yes
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Memory channels: Dual-channel
Supported memory clock speed (max): 7200 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Height: 35 mm
Depth: 225 mm
Width: 230 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Front panel connector: Yes
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Total number of SATA connectors: 4
12V power connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package width: 265 mm
Package weight: 897 g
Package height: 54 mm
Package depth: 265 mm
Bundled software: Norton Internet Security
LAN bandwidth management software
Packaging content
Cables included: SATA
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 0, 10, 1
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of storage drives supported: 5
Number of HDDs supported: 4
Rear panel I/O ports
USB connector type: USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 1.4
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
PS/2 ports quantity: 1
HDMI version: 2.1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Headphone outputs: 3
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 slots: 1
PCI Express x1 slots: 1
Battery
Battery type: CR2032
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste.
