Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM4
Compatible processor series: AMD Ryzen 4000 Series, AMD Ryzen 3000 Series, AMD Ryzen 5000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM4
Graphics
On-board graphics card: No
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 5120 x 2880 pixels
DirectX version: 12.0
Features
Motherboard chipset: AMD B550
PC health monitoring: Fan, Voltage, Temperature
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Product colour: Dark brown
Motherboard chipset family: AMD
Power source type: ATX
Audio chip: Realtek ALC1220-VB
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 32 GB
Supported memory clock speed (max): 3200 MHz
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 2400, 3200, 2667, 2933, 2133
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8851BE
Bluetooth version: 5.3
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek RTL8111H
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Internal I/O
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 5
RGB LED pin header: Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 2.0 connectors: 1
Number of chassis fan connectors: 2
EPS power connector (8-pin): Yes
CPU fan connector: Yes
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
TPM connector: Yes
ATX Power connector (24-pin): Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Packaging data
Package weight: 1.24 kg
Package width: 270 mm
Package depth: 268 mm
Package height: 68 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Batteries included: Yes
Antenna included: Yes
Storage controllers
Number of storage drives supported: 6
Number of HDDs supported: 4
RAID levels: 1, 0, 10
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0, SATA III
Rear panel I/O ports
Headphone outputs: 1
WiFi-AP antenna jack: 2
PS/2 ports quantity: 1
Line-in: Yes
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI version: 2.1
DisplayPort version: 1.4
HDMI ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
2nd M.2 highest PCI Express generation: 3.0
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Other features
Weight: 1.14 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
