Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Motherboard form factor: ATX
PC health monitoring: Water cooling, Temperature, Voltage, Fan
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Power source type: ATX
Motherboard chipset: AMD B650
Product colour: White
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 4
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8000 MHz
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 6400, 5200, 8000, 6600, 6200, 6666, 6000, 4800, 7000, 4400, 6800, 5600, 7200 MHz, 7600, 7800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 35 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax), 802.11b
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
WLAN controller model: MediaTek MT7925
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
Number of SATA III connectors: 4
Number of CPU fan connectors: 2
Front panel connector: Yes
Number of RGB LED pin headers: 3
Number of EPS power connectors (8-pin): 1
Number of chassis fan connectors: 4
Number of water pump connectors: 2
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
CPU fan connector: Yes
TPM connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
USB 3.2 Gen 2x2 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 345 mm
Package height: 80 mm
Package weight: 3.56 kg
Package depth: 294 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Drivers included: Yes
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID levels: 1, 0, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPort version: 1.4
HDMI version: 2.1
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
Microphone in: Yes
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
Number of M.2 (M) slots: 3
1st M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste.
