Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
PC health monitoring: Water cooling, Temperature, Voltage, Fan
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Power source type: ATX
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Product colour: White
Memory
Supported memory clock speeds: 5600, 7200, 6400 MHz, 7000, 6200, 6666, 6600, 6000, 6800, 5200, 4800, 4400, 7600, 7800, 8000
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Unbuffered memory: Yes
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory clock speed (max): 8000 MHz
Maximum internal memory per slot: 64 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8125
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b, 802.11g, Wi-Fi 5 (802.11ac)
Ethernet interface type: 2.5 Gigabit Ethernet
WLAN controller model: Realtek RTL8852CE
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
Serial port headers: 1
12V power connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
Front panel connector: Yes
TPM connector: Yes
Number of water pump connectors: 2
RGB LED pin header: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 5
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package weight: 1.89 kg
Package width: 270 mm
Package height: 68 mm
Package depth: 268 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Batteries included: Yes
Antenna included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 1, 10, 0
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
USB 2.0 ports quantity: 4
HDMI version: 2.1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
S/PDIF out port: Yes
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-in: Yes
Digital audio optical out: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 2
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 25110
1st M.2 largest key size: 25110
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
