Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
DirectX version: 12.0
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
Features
Audio chip: Realtek ALC897
Product colour: Bronze
Motherboard chipset: AMD B650
Motherboard form factor: micro ATX
PC health monitoring: Fan, Temperature, Voltage
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Power source type: ATX
Cooling type: Passive
Memory
Maximum internal memory per slot: 64 GB
ECC сompatibility: Non-ECC
Supported memory clock speeds: 6200, 5200, 6000, 6400, 6800, 7600, 7800, 5600, 7200, 4800 MHz, 6600, 7000, 8000 MHz
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speed (max): 8000 MHz
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 244 mm
Network
LAN controller: Realtek RTL8125
Bluetooth: Yes
WLAN controller model: Realtek RTL8852CE
Bluetooth version: 5.3
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 3
Number of EPS power connectors (8-pin): 1
12V power connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 2
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
USB 2.0 connectors: 2
EPS power connector (8-pin): Yes
TPM connector: Yes
Front panel connector: Yes
Front panel audio connector: Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Packaging data
Package height: 68 mm
Package depth: 268 mm
Package width: 270 mm
Package weight: 1.2 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
RAID levels: 1, 10, 0
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
DisplayPorts quantity: 2
PS/2 ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.4
HDMI ports quantity: 1
Line-in: Yes
USB 2.0 ports quantity: 2
Headphone outputs: 1
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
Expansion slots
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
1st M.2 largest key size: 2580
1st M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
Battery
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
