Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core i9 14th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i3 13th Gen, Intel Core i3 12th Gen, Intel Core i9 13th Gen, Intel Core i7 13th Gen, Intel® Celeron®, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i3 14th Gen
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Processor manufacturer: Intel
Graphics
DirectX version: 12.0
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Features
PC health monitoring: Temperature, Water cooling, Fan, Voltage
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Product colour: Dark brown
Motherboard form factor: ATX
Power source type: ATX
Component for: PC
Audio chip: Realtek ALC897
Cooling type: Passive
Motherboard chipset: Intel B760 Express
Memory
Supported memory clock speed (max): 5600 MHz
Supported memory clock speeds: 4800 MHz, 5600, 5200, 4400 MHz
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Bluetooth: Yes
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11b, 802.11a, Wi-Fi 6 (802.11ax)
WLAN controller model: Intel Wi-Fi 6E AX210
Ethernet interface type: Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Serial port headers: 1
ATX Power connector (24-pin): Yes
Number of water pump connectors: 2
Front panel connector: Yes
12V power connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
TPM connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 4
Number of CPU fan connectors: 2
RGB LED pin header: Yes
Number of SATA III connectors: 4
S/PDIF out connector: Yes
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 4
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS memory size: 128 Mbit
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
ACPI version: 5.0
Packaging data
Package weight: 1.55 kg
Package height: 80 mm
Package depth: 270 mm
Package width: 335 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
RAID support: Yes
RAID levels: 0, 10, 1, 5
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 2x2 Type-C ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.2
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
HDMI ports quantity: 1
Headphone outputs: 1
Line-in: Yes
USB 2.0 ports quantity: 4
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
WiFi-AP antenna jack: 2
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 4
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
Battery
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Other features
Weight: 1.31 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
