Processor
Compatible processor series: Intel Core i3 14th Gen, Intel® Celeron®, Intel Core i9 13th Gen, Intel Core i3 12th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i9 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 13th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor socket: LGA 1700
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Features
Motherboard form factor: ATX
PC health monitoring: Fan, Water cooling, Voltage, Temperature
Audio output channels: 7.1 channels
Motherboard chipset: Intel B760
Motherboard chipset family: Intel
Power source type: ATX
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Supported memory clock speed (max): 7600 MHz
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory clock speeds: 6200, 7400, 7600, 6400 MHz, 6600, 4000, 4800, 5200, 5600, 7200, 6800, 5800, 5400, 6000, 7000
Maximum internal memory: 256 GB
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
Number of water pump connectors: 2
Number of CPU fan connectors: 2
RGB LED pin header: Yes
12V power connector: Yes
TPM connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
S/PDIF out connector: Yes
Number of SATA III connectors: 4
Front panel connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID levels: 10, 1, 0, 5
Supported storage drive types: HDD & SSD
RAID support: Yes
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 5
DisplayPort version: 1.2
Expansion slots
2nd M.2 largest key size: 22110
1st M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
