Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i3 12th Gen, Intel Core i5 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 14th Gen, Intel® Celeron®, Intel Core i9 13th Gen, Intel Core i7 13th Gen, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i9 14th Gen, Intel Core i7 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
Features
PC health monitoring: Water cooling, Fan, Voltage, Temperature
Component for: PC
Product colour: Dark brown
Power source type: ATX
Motherboard chipset family: Intel
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Motherboard chipset: Intel B760
Memory
Supported memory clock speeds: 4400, 4800, 5200, 5600
Memory channels: Dual-channel
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Supported memory clock speed (max): 5600 MHz
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Weight & dimensions
Height: 35 mm
Width: 305 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
LAN controller: Realtek RTL8125
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
WLAN controller model: Intel Wi-Fi 6E AX210
Internal I/O
Front panel audio connector: Yes
Serial port headers: 1
CPU fan connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 4
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
Front panel connector: Yes
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
12V power connector: Yes
RGB LED pin header: Yes
Number of RGB LED pin headers: 4
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 1
Number of water pump connectors: 2
BIOS
BIOS memory size: 256 Mbit
ACPI version: 5.0
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 80 mm
Package width: 335 mm
Package weight: 1.8 kg
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
RAID levels: 10, 0, 5, 1
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Number of storage drives supported: 7
Rear panel I/O ports
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
DisplayPort version: 1.2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 5
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Line-in: Yes
HDMI version: 2.1
Microphone in: Yes
WiFi-AP antenna jack: 2
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Other features
Weight: 1.61 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
