Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i3 12th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i7 13th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 14th Gen, Intel Core i9 13th Gen, Intel® Celeron®, Intel Core i3 13th Gen, Intel Core i9 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
DirectX version: 12.0
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
Features
Motherboard form factor: micro ATX
Motherboard chipset: Intel B760 Express
Power source type: ATX
PC health monitoring: Water cooling, Voltage, Temperature, Fan
Audio output channels: 7.1 channels
Product colour: Black
Motherboard chipset family: Intel
Cooling type: Passive
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Supported memory clock speeds: 5200, 6000, 6800, 6200, 4000, 4800, 6400 MHz, 7400, 5800, 5400, 7000, 5600, 7200, 6600, 7600, 7800
Unbuffered memory: Yes
Maximum internal memory: 256 GB
ECC сompatibility: ECC & Non-ECC
Supported memory clock speed (max): 7800 MHz
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Weight & dimensions
Height: 35 mm
Width: 244 mm
Depth: 244 mm
Network
Bluetooth: Yes
WLAN controller model: Intel Wi-Fi 6E AX210
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: 802.11 ac, 802.11b, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), 802.11 ax, Wi-Fi 5 (802.11ac), 802.11n
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of chassis fan connectors: 3
USB 2.0 connectors: 4
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
Thunderbolt headers: 2
Front panel audio connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
12V power connector: Yes
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 4
TPM connector: Yes
Front panel connector: Yes
BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package weight: 1.75 kg
Package width: 270 mm
Package height: 68 mm
Package depth: 268 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 1, 0, 5, 10
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
Number of storage drives supported: 6
Rear panel I/O ports
DisplayPorts quantity: 1
USB 2.0 ports quantity: 4
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
WiFi-AP antenna jack: 2
Headphone outputs: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Line-in: Yes
HDMI version: 2.1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
Battery
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Other features
Weight: 1.33 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
