Technical details
Warranty period: 3 year(s)
Processor
Maximum internal memory supported by processor: 128 GB
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Processor manufacturer: Intel
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11, Windows 10
Motherboard chipset: Intel B760 Express
Power source type: ATX
PC health monitoring: Temperature, Water cooling, Voltage, Fan
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Product colour: Bronze
Audio output channels: 7.1 channels
Memory
Memory slots type: DIMM
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 4133, 2933, 3600, 3200 MHz, 2133, 3000, 3733, 4000, 3400, 3800, 3333, 3466, 2666, 2400, 3300, 4600, 4300, 4400, 3866, 4700, 4500, 3666, 4800, 4933 MHz, 4266, 5133, 5000, 5333 MHz
Unbuffered memory: Yes
Supported memory module capacities: 8GB, 32GB, 2GB, 4GB, 12GB, 16GB, 1GB
Maximum internal memory: 128 GB
Supported memory clock speed (max): 5333 MHz
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Height: 35 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Internal I/O
RGB LED pin header: Yes
Total number of SATA connectors: 4
12V power connector: Yes
Front panel connector: Yes
TPM connector: Yes
Audio connector: Yes
Power fan connector: Yes
S/PDIF out connector: Yes
Number of SATA III connectors: 4
Parallel connector: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
Number of Parallel ATA connectors: 1
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Serial port headers: 1
Number of chassis fan connectors: 3
CPU fan connector: Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Packaging data
Package height: 54 mm
Package width: 265 mm
Package depth: 265 mm
Package weight: 990 g
Bundled software: Norton Internet Security
Packaging content
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 6
RAID levels: 0, 10, 1, 5
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
Headphone outputs: 1
VGA (D-Sub) ports quantity: 1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Microphone in: Yes
Line-in: Yes
HDMI version: 2.1
HDMI ports quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-A
Digital audio optical out: 3
DisplayPorts quantity: 2
USB 2.0 ports quantity: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 slots: 1
PCI Express x4 slots: 1
PCI Express x16 slots: 1
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
Battery
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Do not open the memory module housing., Dispose of in accordance with local regulations for electronic waste., Protect from extreme temperatures.
