Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i3 13th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i7 13th Gen, Intel Core i3 12th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel® Celeron®, Intel Core i3 14th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
HDCP: Yes
DirectX version: 12.0
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
Features
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Audio chip: Realtek ALC897
Product colour: Grey, Black
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Power source type: ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel B760 Express
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 48 GB
Supported memory clock speeds: 4800, 4400, 5600 MHz, 5200
Maximum internal memory: 192 GB
Unbuffered memory: Yes
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 5600 MHz
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 244 mm
Network
LAN controller: Realtek RTL8111H
Bluetooth: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11ac, 802.11 b/g/n
Wi-Fi: Yes
WLAN controller model: Realtek RTL8851BE
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet interface type: Gigabit Ethernet
Bluetooth version: 5.3
Internal I/O
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 2
S/PDIF out connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
12V power connector: Yes
Parallel connector: Yes
TPM connector: Yes
Front panel connector: Yes
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 3
Serial port headers: 1
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging data
Package depth: 265 mm
Package width: 265 mm
Package weight: 1.2 kg
Package height: 54 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 1, 10, 5, 0
Number of storage drives supported: 3
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPorts quantity: 1
DisplayPort version: 1.2
Ethernet LAN (RJ-45) ports: 1
WiFi-AP antenna jack: 2
VGA (D-Sub) ports quantity: 1
HDMI version: 2.1
Headphone outputs: 1
USB 2.0 ports quantity: 2
PS/2 ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Line-in: Yes
Expansion slots
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
Battery
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Other features
Weight: 1.11 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
