Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i3 14th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i7 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel Core i3 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i3 12th Gen, Intel® Celeron®, Intel Core i9 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Product colour: Dark brown
Cooling type: Passive
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: Intel B760
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Component for: PC
Power source type: ATX
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 4000, 4800, 6600, 6400, 5200, 6200, 6000, 6800, 7000, 5600, 7200 MHz, 5800, 5400
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Maximum internal memory: 128 GB
Number of memory slots: 2
Memory channels: Dual-channel
Unbuffered memory: Yes
Supported memory clock speed (max): 7200 MHz
Weight & dimensions
Depth: 215 mm
Height: 35 mm
Width: 230 mm
Network
Wi-Fi: No
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 1
CPU fan connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
RGB LED pin header: Yes
S/PDIF out connector: Yes
Number of SATA III connectors: 4
TPM connector: Yes
12V power connector: Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 2
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 128 Mbit
ACPI version: 5.0
Packaging data
Package height: 54 mm
Package width: 265 mm
Package depth: 265 mm
Package weight: 900 g
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 1, 0, 5, 10
Number of storage drives supported: 6
Number of HDDs supported: 4
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Line-in: Yes
DisplayPort version: 1.2
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI version: 2.1
DisplayPorts quantity: 1
Microphone in: Yes
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
HDMI ports quantity: 1
Expansion slots
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
