Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 128 GB
Processor manufacturer: Intel
Compatible processor series: Intel Core i5 12th Gen, Intel Core i9 14th Gen, Intel Core i5 13th Gen, Intel Core i3 12th Gen, Intel® Celeron®, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i7 13th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i9 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i3 14th Gen
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Power source type: ATX
Component for: PC
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Product colour: Grey
PC health monitoring: Fan, Voltage, Water cooling, Temperature
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Memory
Supported memory clock speeds: 2400, 3200 MHz, 2666, 4133, 4000, 2933, 3600, 2133, 3000, 5333 MHz, 3733, 4300, 4400, 5000, 4700, 3800, 3333, 4266, 4600, 3466, 3666, 4800, 4933 MHz, 3300, 5133, 3400, 3866, 4500
Memory channels: Dual-channel
Maximum internal memory per slot: 32 GB
Supported memory clock speed (max): 5333 MHz
ECC сompatibility: ECC & Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm
Network
LAN controller: Realtek RTL8111H
WLAN controller model: Realtek RTL8851BE
Bluetooth: Yes
Bluetooth version: 5.3
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet interface type: Gigabit Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
RGB LED pin header: Yes
Number of chassis fan connectors: 3
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
ATX Power connector (24-pin): Yes
Serial port headers: 1
Parallel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
Front panel connector: Yes
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 2
Number of CPU fan connectors: 1
S/PDIF out connector: Yes
USB 2.0 connectors: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
ACPI version: 5.0
BIOS memory size: 128 Mbit
Clear CMOS jumper: Yes
Packaging data
Package weight: 1.2 kg
Package width: 270 mm
Package depth: 268 mm
Package height: 68 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
RAID support: Yes
RAID levels: 10, 0, 1, 5
Number of storage drives supported: 6
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Line-in: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
WiFi-AP antenna jack: 2
DisplayPort version: 1.2
HDMI version: 2.1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Headphone outputs: 1
DisplayPorts quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 3.x) slots: 2
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 4.0
Battery
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 1.1 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
