Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i3 12th Gen, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i7 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel® Celeron®, Intel Core i9 14th Gen, Intel Core i3 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
DirectX version: 12.0
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Features
PC health monitoring: Temperature, Fan, Water cooling, Voltage
Motherboard chipset: Intel B760
Motherboard form factor: micro ATX
Power source type: ATX
Cooling type: Passive
Component for: PC
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: Intel
Product colour: Dark brown
Audio chip: Realtek ALC897
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speeds: 4400, 5600, 5200, 4800
Unbuffered memory: Yes
Maximum internal memory per slot: 64 GB
Maximum internal memory: 256 GB
ECC сompatibility: ECC & Non-ECC
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory clock speed (max): 5600 MHz
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Height: 35 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
WLAN controller model: Intel Wi-Fi 6E AX210
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
USB 2.0 connectors: 2
Number of chassis fan connectors: 3
Serial port headers: 1
S/PDIF out connector: Yes
12V power connector: Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel audio connector: Yes
Thunderbolt headers: 2
CPU fan connector: Yes
Front panel connector: Yes
TPM connector: Yes
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
BIOS
ACPI version: 5.0
BIOS memory size: 256 Mbit
System Management BIOS (SMBIOS) version: 2.7
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package height: 68 mm
Package width: 270 mm
Package weight: 1.6 kg
Package depth: 268 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Batteries included: Yes
Antenna included: Yes
Storage controllers
RAID levels: 0, 10, 1, 5
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
RAID support: Yes
Rear panel I/O ports
Line-in: Yes
USB 2.0 ports quantity: 5
Headphone outputs: 1
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
WiFi-AP antenna jack: 2
HDMI version: 2.1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
DisplayPort version: 1.2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
Battery
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 1.42 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
