Technical details
Warranty period: 3 year(s)
Processor
Processor socket: LGA 1700
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor manufacturer: Intel
Maximum internal memory supported by processor: 64 GB
Maximum number of SMP processors: 1
Supported processor sockets: LGA 1700
Graphics
DirectX version: 12.1
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11, Windows 10
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Component for: PC
Motherboard chipset: Intel B760 Express
Product colour: Bronze
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Power source type: ATX
Memory
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Supported memory clock speed (max): 3200 MHz
ECC сompatibility: Non-ECC
Supported memory clock speeds: 2400, 3200 MHz, 2666, 3000, 2933, 2133
Supported memory module capacities: 8GB, 1GB, 32GB, 2GB, 4GB, 16GB, 12GB
Maximum internal memory: 64 GB
Weight & dimensions
Depth: 215 mm
Height: 35 mm
Width: 230 mm
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Internal I/O
RGB LED pin header: Yes
Total number of SATA connectors: 4
ATX Power connector (24-pin): Yes
Serial port headers: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 128 Mbit
ACPI version: 5.0
Packaging data
Package height: 54 mm
Package weight: 825 g
Package depth: 265 mm
Package width: 265 mm
Packaging content
Batteries included: Yes
Storage controllers
Number of storage drives supported: 6
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, SATA III
RAID levels: 5, 1, 0, 10
RAID support: Yes
Rear panel I/O ports
HDMI version: 1.4
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
Battery
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
