Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core i9 14th Gen, Intel® Celeron®, Intel Core i3 13th Gen, Intel Core i3 12th Gen, Intel Core i5 13th Gen, Intel Core i3 14th Gen, Intel Core i9 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i7 13th Gen, Intel® Pentium® Gold, Intel Core i9 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Graphics
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
HDCP version: 2.3
Parallel processing technology support: Not supported
HDCP: Yes
Features
Motherboard chipset: Intel B760 Express
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Product colour: Dark brown
Audio output channels: 7.1 channels
PC health monitoring: Water cooling, Voltage, Temperature, Fan
Cooling type: Passive
Audio chip: Realtek ALC897
Power source type: ATX
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Component for: PC
Memory
Supported memory clock speeds: 7000, 6000, 7600, 7800, 5600, 7200, 6600, 6800, 6200, 5200, 5800, 5400, 7400, 6400 MHz, 4000, 4800, 8000
Number of memory slots: 2
Maximum internal memory per slot: 64 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Supported memory clock speed (max): 8000 MHz
Maximum internal memory: 128 GB
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Weight & dimensions
Height: 35 mm
Depth: 220 mm
Width: 244 mm
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
LAN controller: Realtek RTL8111H
Wi-Fi: No
Internal I/O
Number of chassis fan connectors: 2
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 1
EPS power connector (8-pin): Yes
CPU fan connector: Yes
TPM connector: Yes
Number of SATA III connectors: 4
Serial port headers: 1
Front panel audio connector: Yes
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 2
12V power connector: Yes
Front panel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS
BIOS memory size: 128 Mbit
System Management BIOS (SMBIOS) version: 2.7
ACPI version: 5.0
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 54 mm
Package weight: 850 g
Package width: 265 mm
Package depth: 265 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 0, 10, 1, 5
Number of storage drives supported: 5
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
Rear panel I/O ports
Line-in: Yes
USB 2.0 ports quantity: 4
Headphone outputs: 1
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
DisplayPort version: 1.2
DisplayPorts quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 2280
Number of M.2 (M) slots: 1
1st M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Battery capacity: 220 mAh
Battery weight: 3 g
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 770 g
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
