Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Graphics
HDCP version: 2.3
DirectX version: 12.0
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Features
PC health monitoring: Temperature, Water cooling, Voltage, Fan
Cooling type: Passive
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: AMD B840
Component for: PC
Power source type: ATX
Product colour: Dark brown
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Supported memory clock speeds: 7600, 6800, 6000, 7000, 6200, 6666, 6600, 6400 MHz, 5200, 5600, 7200, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 7600 MHz
Maximum internal memory per slot: 64 GB
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Height: 35 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: Yes
WLAN controller model: Realtek RTL8852CE
Bluetooth version: 5.3
LAN controller: Realtek RTL8125
Bluetooth: Yes
Wi-Fi standards: 802.11g, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
RGB LED pin header: Yes
12V power connector: Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
Number of water pump connectors: 2
Number of RGB LED pin headers: 4
Peripheral (Molex) power connectors (4-pin): 1
Front panel connector: Yes
Number of CPU fan connectors: 2
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of EPS power connectors (8-pin): 1
BIOS
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
ACPI version: 5.0
Clear CMOS jumper: Yes
Clear CMOS button: Yes
Packaging data
Package weight: 1.89 kg
Package height: 80 mm
Package width: 335 mm
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
RAID levels: 0, 1, 10, 5
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Rear panel I/O ports
Headphone outputs: 1
WiFi-AP antenna jack: 2
Line-in: Yes
Microphone in: Yes
DisplayPorts quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 3
3rd M.2 highest PCI Express generation: 3.0
1st M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 25110
2nd M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 25110
Battery
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Other features
Weight: 1.66 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
