Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
PC health monitoring: Water cooling, Fan, Temperature, Voltage
Motherboard form factor: micro ATX
Motherboard chipset: AMD B840
Cooling type: Passive
Power source type: ATX
Component for: PC
Audio output channels: 7.1 channels
Product colour: Dark brown
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Memory
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory clock speed (max): 8200 MHz
Number of memory slots: 4
Supported memory clock speeds: 7600, 7800, 5600, 7200, 6800, 6000, 7000, 8200, 6400 MHz, 6200, 6666, 5200, 6600, 4400, 7950, 7900, 7400, 8000, 4800
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm
Network
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
WLAN controller model: Realtek RTL8851BE
Ethernet LAN: Yes
LAN controller: Realtek RTL8125
Bluetooth: Yes
Internal I/O
Number of water pump connectors: 2
USB 2.0 connectors: 2
Number of RGB LED pin headers: 3
Number of CPU fan connectors: 2
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 2
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
BIOS
ACPI version: 5.0
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 270 mm
Package height: 68 mm
Package weight: 1.23 kg
Package depth: 268 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Batteries included: Yes
Antenna included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 1, 0, 10, 5
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DisplayPorts quantity: 2
HDMI ports quantity: 1
PS/2 ports quantity: 1
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
WiFi-AP antenna jack: 2
Microphone in: Yes
Line-in: Yes
Headphone outputs: 1
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
2nd M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2580
Number of M.2 (M) slots: 2
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery weight: 3 g
Other features
Weight: 1.13 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
