Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
HDCP: Yes
HDCP version: 2.3
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
PC health monitoring: Fan, Temperature, Voltage, Water cooling
Motherboard chipset: AMD B840
Cooling type: Passive
Component for: PC
Audio output channels: 7.1 channels
Power source type: ATX
Motherboard chipset family: AMD
Product colour: Dark brown
Audio chip: Realtek ALC897
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory clock speeds: 5800, 6600, 6400 MHz, 6200, 6000, 7600, 7800, 6800, 7400, 8000, 7000, 8200, 7950, 7900, 5600, 7200
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
Maximum internal memory per slot: 64 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 244 mm
Network
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
WLAN controller model: MediaTek MT7902
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Bluetooth version: 5.3
Bluetooth: Yes
LAN controller: Realtek RTL8111H
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
EPS power connector (8-pin): Yes
Front panel connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
USB 2.0 connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 2
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 4
BIOS
ACPI version: 5.0
Clear CMOS jumper: Yes
BIOS memory size: 256 Mbit
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package height: 68 mm
Package width: 270 mm
Package depth: 268 mm
Package weight: 1.24 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
RAID levels: 0, 10, 1, 5
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Headphone outputs: 1
Line-in: Yes
Microphone in: Yes
DisplayPorts quantity: 2
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
WiFi-AP antenna jack: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 3
DisplayPort version: 1.4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
1st M.2 largest key size: 2580
1st M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
Battery
Number of battery cells: 1
Battery type: CR2032
Battery capacity: 220 mAh
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Other features
Weight: 1.15 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
