Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Graphics
DirectX version: 12.0
On-board graphics card: No
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
Features
Motherboard chipset: AMD B850
Product colour: Black, Bronze
Audio chip: Realtek ALC897
PC health monitoring: Fan, Temperature, Water cooling, Voltage
Power source type: ATX
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Supported memory clock speeds: 6600, 7400, 6000, 4400, 7950, 7900, 5200, 6800, 4800, 7600, 7800, 7000, 8200, 6200, 6400 MHz, 5800, 5600, 7200, 8000
Number of memory slots: 4
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Maximum internal memory per slot: 64 GB
Memory slots type: DIMM
Supported memory clock speed (max): 8200 MHz
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Height: 35 mm
Network
WLAN controller model: Realtek RTL8922AE
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Bluetooth: Yes
Internal I/O
Number of water pump connectors: 2
Number of RGB LED pin headers: 4
Total number of SATA connectors: 4
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 2x2 connectors: 1
12V power connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
Number of CPU fan connectors: 2
Number of SATA III connectors: 4
Front panel connector: Yes
Serial port headers: 1
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
USB 2.0 connectors: 2
CPU fan connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Peripheral (Molex) power connectors (4-pin): 1
Front panel audio connector: Yes
BIOS
Clear CMOS button: Yes
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package height: 80 mm
Package depth: 270 mm
Package width: 335 mm
Package weight: 2.46 kg
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Number of HDDs supported: 4
RAID support: Yes
RAID levels: 0, 10, 1
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
WiFi-AP antenna jack: 2
HDMI version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
Expansion slots
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 3
Battery
Number of battery cells: 1
Battery type: CR2032
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Other features
Weight: 2.13 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
