Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Component for: PC
Cooling type: Passive
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
PC health monitoring: Voltage, Water cooling, Fan, Temperature
Motherboard chipset: AMD B850
Product colour: White
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Motherboard form factor: ATX
Power source type: ATX
Memory
Supported memory clock speed (max): 8200 MHz
Number of memory slots: 4
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 6600, 6800, 6200, 5600, 7200 MHz, 5200, 6000, 7600, 7800, 8000, 4800, 7000, 8200 MHz, 6400, 7400, 4400, 7950, 7900, 5800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Wi-Fi standards: 802.11g, 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n)
WLAN controller model: Realtek RTL8922AE
Ethernet LAN: Yes
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
LAN controller: Realtek RTL8126
Bluetooth: Yes
Internal I/O
Peripheral (Molex) power connectors (4-pin): 1
12V power connector: Yes
USB 3.2 Gen 2x2 connectors: 1
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
CPU fan connector: Yes
Front panel connector: Yes
Number of chassis fan connectors: 6
TPM connector: Yes
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 4
Number of temperature sensor headers: 2
Number of noise detection headers: 1
Number of water pump connectors: 3
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 2
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 512 Mbit
Clear CMOS jumper: Yes
ACPI version: 5.0
Packaging data
Package height: 92 mm
Package width: 310 mm
Package depth: 340 mm
Package weight: 4.14 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID levels: 0, 1, 10, 5
Number of storage drives supported: 6
Number of HDDs supported: 2
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports
HDMI version: 2.1
WiFi-AP antenna jack: 2
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Digital audio optical out: 1
Headphone outputs: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 largest key size: 22110
1st M.2 largest key size: 25110
4th M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 5.0
4th M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
Battery
Battery type: CR2032
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Other features
Weight: 3.63 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
