Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11 x64
Motherboard chipset family: AMD
PC health monitoring: Water cooling, Fan, Voltage, Temperature
Product colour: White
Cooling type: Passive
Motherboard form factor: ATX
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Power source type: ATX
Memory
Memory slots type: DIMM
Number of memory slots: 4
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 8200 MHz
Supported memory clock speeds: 7600, 7800, 8000, 6000, 4400, 7950, 7900, 7000, 8200 MHz, 6600, 7400, 6400, 5600, 7200 MHz, 6800, 4800, 5200, 5800, 6200
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Height: 35 mm
Width: 305 mm
Depth: 244 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Internal I/O
12V power connector: Yes
Front panel connector: Yes
TPM connector: Yes
Number of water pump connectors: 2
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Peripheral (Molex) power connectors (4-pin): 1
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of chassis fan connectors: 4
USB 2.0 connectors: 2
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package height: 80 mm
Package width: 335 mm
Package depth: 270 mm
Package weight: 1.88 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 10, 0, 1
Rear panel I/O ports
HDMI version: 2.1
Line-in: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
PS/2 ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
Expansion slots
3rd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
Battery
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Battery type: CR2032
Other features
Weight: 1.65 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
